Tubular sound absorber

RSKI 90/2000

Article number: 0073.0120
Manufacturer: MAICO
Available on request
Duct silencer with baffle, length 1800 mm, DN 900

Product data sheet
RSKI 90/2000 IM0021239.PNG Duct silencer with baffle, length 1800 mm, DN 900
Back
  • On the notes
RSKI 63/1000
RSKI 63/1500
RSKI 63/2000
RSKI 71/1000
RSKI 71/1500
RSKI 71/2000
RSKI 80/1000
RSKI 80/1500
RSKI 80/2000
RSKI 90/1000
RSKI 90/1500
RSKI 90/2000
RSKI 100/1000
RSKI 100/1500
RSKI 100/2000
RSKI 112/1000
RSKI 112/1500
RSKI 112/2000
RSKI 125/1000
RSKI 125/1500
RSKI 125/2000

Characteristic curve

Dimensioned drawing

RSKI 90/2000 - Dimensioned drawing [mm]

Technical data

RSKI 90/2000 - Technical data

Article RSKI 90/2000
Material Steel, galvanised
Colour Silver
Weight 175 kg
Weight including packaging 175 kg
Nominal size 900 mm
Width 1.100 mm
Height 1.100 mm
Depth 1.800 mm
Width with packaging 1.100 mm
Height with packaging 1.100 mm
Depth with packaging 1.800 mm
Insertion loss at 63 Hz 4 dB
Insertion loss at 125 Hz 7 dB
Insertion loss at 250 Hz 17 dB
Insertion loss at 500 Hz 30 dB
Insertion loss at 1 kHz 34 dB
Insertion loss at 2 kHz 20 dB
Insertion loss at 4 kHz 12 dB
Insertion loss at 8 kHz 11 dB
Packing unit 1 piece
Range C
GTIN (EAN) 4012799731207
Article number 0073.0120

Product description

Productdescription

RSKI 90/2000

short description

Duct silencer with baffle, length 1800 mm, DN 900

Product description

  • Cylindrical sound absorber for ventilation systems.
  • Version with baffle for higher noise damping.
  • The inside of the sound absorber is made of a perforated plate.
  • Operating temperature between -40 °C and +150 °C.

Table of contents

Wiring diagram

RSKI 90/2000 - Wiring diagram
